A-9030/9050-Connecting a Cassette Tape Deck

Please use the following procedure to connect a cassette tape deck to the A-9030/A-9050 Integrated Amplifier.

TIP

Connect your cassette tape deck to either of the following jacks: LINE IN 1/2/3/4

If there is no sound:

• Make sure the integrated amplifier’s volume control is not set to minimum
• Make sure the correct input source is selected
• Make sure the integrated amplifier is not muted
• Make sure the speakers are connected correctly

If the sound is distorted or sound quality is not good:

• Make sure the speaker cables are connected with the correct polarity
• Make sure all audio connecting plugs are pushed in all the way
• The sound quality can be affected by strong magnetic fields, such as those from a TV. Try moving any such devices away from the integrated amplifier
• Using cable ties to bundle audio cables with speaker or power cables may degrade the sound quality, so refrain from doing it
• Plug the power cord into an AC wall outlet
• Install the integrated amplifier on a sturdy rack or shelf. Position it so that its weight is evenly dispersed on its four legs. Do not install the integrated amplifier in a place with vibration or an unstable location.
