When you connect wireless headphones or a wireless speaker transmitter to the ZONE B LINE OUT terminal of this unit, you can play back the same source through the wireless headphones or wireless speakers as in the main room.

Connections

1. Use an analog audio cable to connect the ZONE B LINE OUT terminal on this unit to the input terminal on the transmitter.




Setting Up

1. Press on the remote controller, and set "2. Speaker" - "Configuration" - "Zone 2 Lineout" to "Zone B".

Playing Back

1. Press the Q button on the remote controller and select "Audio" - "Zone B".
   • In the following cases, "Zone B" cannot be selected.
   – When ZONE 2 is On
   – When "2. Speaker" - "Configuration" - "Zone 2 Lineout" on the Setup menu is set to "Zone 2".
2. Select the audio output destination.
   Off: Outputs audio only from ZONE A. "A" on the display of the main unit lights up.
   On (A+B): Outputs audio from both ZONE A and ZONE B. "A" and "B" on the display of the main unit light up.
   On (B): Outputs audio only from ZONE B. "B" on the display of the main unit lights up.



3. Start play on the AV component.
4. Adjust the volume on the transmitter, etc., in ZONE B.

   • When "Zone 2 Lineout" is set to "Zone B", and "Audio" - "Zone B" on the Quick Menu is set to "On (A+B)", the ZONE A output is set as below.

   – Sound quality cannot be adjusted.
   – There will be no effect for the surround back speakers from "2.Speaker" - "Distance" in the Setup menu.

   • If "On (A+B)" is selected as an audio output destination, you can select only the "Stereo" listening mode for ZONE A when using the 2.1 ch speaker layout.  When using a speaker layout of 3.1 ch or more, you can select only the "AllCh Stereo" listening mode.
